The ORION 2.0 represents the cutting-edge advancement within the transparent LED cabinet series designed specifically for rental applications. Distinguishing itself from previous models, it boasts enhanced durability against environmental factors and physical impact. Additionally, it incorporates features tailored for touring, including corner protections and an optimized toolless locking system. Characterized by its high brightness and straightforward back maintenance, this product proves to be exceptionally well-suited for outdoor touring LED screens.
Application
OUTDOOR
PIXEL PITCH
P3.9a7.8
MAINTENANCE
Back Maintenance
INGRESS PROTECTION
IP65 (front) / IP54 (back)
Display Area (W X H)
1000 x 500 mm
BRIGHTNESS
≤ 6000 NITS
WEIGHT
7.9 kg/cabinet
MATERIAL
Die-casting aluminum
The ORION 2.0 underwent thorough testing for both compressive and tensile load resistance, demonstrating resilience by withstanding pressures of up to 1.8 tons before reaching the breaking point. Combined with the cabinet’s corner protections and flexible masks, this feature ensures the robustness and longevity of your transparent LED cabinet rental fleet.
Equipped with a toolless curving system, the ORION 2.0 facilitates the creation of curved giant LED screens for scenic applications, allowing for angles of up to ±15° between two cabinets. The specially designed hanging bars seamlessly accommodate this feature, ensuring a straightforward assembly process for suspended curved transparent screens.
The ORION 2.0 cabinets are meticulously crafted to enable convenient back-end maintenance at various levels, including the cabinet, module, or power box. Engineered for efficiency, this maintenance process is swift and can be executed by a single qualified technician.
EVENTBack MaintenanceRentalOutdoor90 DegreesTransparentCurveOrion 2.0
| OUTDOOR | ||
| Product Parameters | Unit | 3.9a7.8 |
| Pixel Pitch | mm | 3,91 x 7,81 |
| LED | SMD1921 | |
| Application | Transparent LED Touring Cabinet | |
| Ingress Protection | IP | IP65 (front) / IP54 (back) |
| Brightness | cd/m² | ≤ 6000 Nits @5volts |
| Color Temperature after calib (adjustable) | deg. K | 6500 |
| Viewing Angle (50% brightness) | deg. | 160 H / 160 V |
| Cabinet Size (WxHxD) | mm | 1000 x 500 x85 |
| Display area (WxH) | mm | 1000 x 500 |
| Module Size (WxHxD) | mm | 500 x 250 x 10 |
| Pixel Matrix Per Cabinet (WxH) | px | 256 x 64 |
| Pixel Matrix Per Module (WxH) | px | 128 x 32 |
| Pixel Density | px/m² | 32747 |
| Weight of cabinet and modules | kg | 7.9 |
| Cabinet Material | Die-casting aluminum | |
| Maintenance Mode | Back | |
| Mask specification | 95% Plastic + 5% Fiber / SS Screws / Shaders | |
| Contrast Ratio | High | |
| Grey scale (linear) | bit | 16 |
| Brightness control | bit | 16 |
| Processing depth | bit | 16 |
| Color | 281 Trillions | |
| Display Refresh Rate | Hz | 3840 |
| Operation Power | V | AC85-230V |
| Max. Power Consumption | W/m² | 720 |
| Average Power Consumption | W/m² | 240 |
| Control Mode | Synchronisation | |
| Video Frame Rate | Hz | 50/60Hz |
| Input Types Supported | DVI / SDI / HDMI | |
| 3D ready (optional) | Yes | |
| Calibration | Yes | |
| Lifetime (50% brightness) | h | 50000 |
| Operating Humidity Range | 10-95% | |
| Operating Temperature Range | -20°C / +60°C | |
| Screen Uniformity Correction | - | |
| Certification | CE / ETL / CCC | |
| Options | 90° Bevelled cabinets / Hanging bars / Full Black Face LED | |
| Compatibility | No |
