The COBALT SCOREBOARD was specially designed to be extremely robust but also diffuse your visual content on the brightest LED display cabinet you will find (up to 10000 NITS). Additionally, we’ve implemented a smart heat dissipation system which makes the COBALT SCOREBOARD one of the best cabinets on the market for long-term fixed installations.
Application
OUTDOOR
PIXEL PITCH
P6.6 P8 P10
MAINTENANCE
Back & Front Maintenance
INGRESS PROTECTION
IP68 (front)
IP67 (back)
Display Area (W X H)
960 X 960 mm (STANDARD)
960 X 640 mm
960 X 1280 mm
1440 X 960 mm
BRIGHTNESS
≤10000 NITS @5Volts
WEIGHT
28 KG/SQM
MATERIAL
DIE-CASTING ALUMINUM
Through time, the color uniformity of your LED display usually degrades. This is when the calibration of your screen becomes mandatory. This process will reduce your screen brightness by 5 to 10% (2~3 years). Using 10000 NITS screen allows you to still have a very bright screen after a few years of usage (approximately 7000 NITS after 5 to 6 years).
The COBALT SCOREBOARD cabinets and modules are specially designed to accelerate heat dissipation by letting air circulate between the different components of your LED scoreboard. Reducing heat in an outdoor LED display is one of the best means of preserving its components and ensuring a long lifespan.
Modules and back power supply can be installed and maintained from the back as well as the front of the cabinet. This facilitates the integration and maintenance of your LED scoreboard.
With a 10000 NITS brightness and a 6.67mm to 10mm pixel pitch, you ensure clear visibility from anywhere in your stadium, day or night, to your different sponsors, results, etc.
OUTDOORFront Maintenance90 DegreesSportMultisportSoccerRugbySwimmingBasketballKartingIce RinkScoreboard
| OUTDOOR | ||||
| Product Parameters | Unit | 6.6 | 8 | 10 |
| Pixel Pitch | mm | 6,67 | 8,00 | 10,00 |
| LED | SMD2727 | SMD3535 | SMD3535 | |
| Application | Outdoor ultra high brigthness | |||
| Ingress Protection | IP | IP68 (Front) / IP67 (Rear) | ||
| Brightness | cd/sqm | ≤ 10000 Nits @5volts | ||
| Color Temperature after calib (adjustable) | deg. K | 6500 | ||
| Viewing Angle (50% brightness) | deg. | 180(+/-90) H | ||
| Cabinet Size (WxHxD) | mm | 960 x 1280 x 101 / 960 x 960 x 101 / 960 x 640 x 101 / 1440 x 960 x 101 | ||
| Display area (WxH) | mm | 960 x 1280 / 960 x 960 / 960 x 640 / 1440 x 960 | ||
| Module Size (WxHxD) | mm | 480 x 320 x 26 | ||
| Pixel Matrix Per Cabinet (WxH) | px | 144 x 192 / 144 x 144 / 216 x 144 | 120 x 160 / 120 x 120 / 180 x 120 | 96 x 128 / 96 x 96 / 144 x 96 |
| Pixel Matrix Per Module (WxH) | px | 72 x 48 | 60 x 40 | 48 x 32 |
| Pixel Density | px/sqm | 22500 | 15625 | 10000 |
| Weight | kg/sqm | 28 | ||
| Cabinet Material | Die-casting aluminum | |||
| Maintenance Mode | Back & front | |||
| Mask specification | 95% Plastic + 5% Fiber / SS Screws / Shaders | |||
| Contrast Ratio | High | |||
| Grey scale (linear) | bit | 16 | ||
| Brightness control | bit | 16 | ||
| Processing depth | bit | 16 | ||
| Color | 281 Trillions | |||
| Display Refresh Rate | Hz | 3840 | ||
| Operation Power | V | AC85-230V | ||
| Max. Power Consumption | W/sqm | 550 | ||
| Average Power Consumption | W/sqm | 200 | ||
| Control Mode | Synchronization | |||
| Video Frame Rate | Hz | 50/60Hz | ||
| Input Types Supported | DVI / SDI / HDMI | |||
| 3D ready (optional) | Yes | |||
| Calibration | Yes | |||
| Lifetime (50% brightness) | h | 50000 | ||
| Operating Humidity Range | 10-95% | |||
| Operating Temperature Range | - 20°C / + 60°C | |||
| Screen Uniformity Correction | - | |||
| Certification | EMC CLASS B / CE / ETL / CCC | |||
| Available options | 90° angles, hanging bars | |||
| Compatibility | Cabinets mechanically compatible with each other | |||
